GLOBAL STAR MOTORIZED 400 SATELLITE SYSTEM

Deluxe Motorized 1.2 Meter Ku-Band Satellite System - Global Star System 400

This System Includes the 9000i Linkbox Satellite Receiver that can do DVB-S, DVB-S2, QPSK, 8PSK, 16APSK, MPEG2, MPEG4, Standard and High Definition.
GEO SAT PRO 1.2 Meter Satellite Dish, to gather a stronger Signal and have Less Rain Fade.
HH120 STAB Motor, Our Best Ku LNBF, KSC322 Dual Outlet LNBF and an Installation Kit that includes 1 - 25' and 1 - 75' Black RG6 Coax Cables.

Item # GLOBAL STAR SYS 400 - $659.00 Includes Shipping
Within the 48 Cont. United States

Signal Meter SF95 for $14.95 - This can be helpful in aiming in the dish to locate the satellited.



9000i Linkbox Satellite Receiver
2 Year Manufacturer Warranty

KSC322 DMSI
Dual Outlet LNBF

GEO SAT PRO 1.2 Meter Satellite Dish

DISH Does Not come with Pole.
Heavy Duty 3 inch Dual U-Bolt Mounting Bracket Suitable for Post or Motor Mounts.
Easily inverted for use with top loading motor mounts.

It is best to purchase a 8' - 2.37" Chain Link Fence Post from your local Hardware Store
and place in the ground with 3 - 50 lb bags of Concrete.

HH120 STAB Motor

Get the Most out of your Ku Satellite System
by adding the HH120 STAB Motor and access
several satellites instead of just one.

9000i Linkbox Satellite Receiver
Key Features


  • Dual Input ( Satellite and Terrestrial)
  • WiFi Support
  • ATSC High Definition
  • Ethernet interface- Firmware, data updating
  • BISS CAS Embedded
  • Operate with SMS Control System
  • Twin USB PVR ready -PVR/Time-shift/updating
  • UHF Ready(U-50 Kit Optional)
  • SPDI/F Output (Digital Audio Output)
  • Network TV supported(URL IP Streaming Player)
Main Features
  • Fully Compliant of DVB-S &DVB-S2(QPSK/8PSK/16APSK/32APSK) Digital & DVB broadcasting
  • Supports MPEG2/ MPEG4 AVC HP@level4.1,MP@level 4.1/H.264,VC-1,VP8,AVS
  • High Definition Video output : Digital Output and Y Pb Pr
  • Full HD Resolution supported: 1080p,1080i,720p ,576p,576i,480p,480i
  • Audio Decoding :ISO/IEC13818-3(MPEG-1 layers I, II and III), Dolby AC-3,AAC,HE-AAC
  • Satellite Tuner, 950-2150 MHz input Frequency (IF Loop Throughout),Symbol rate 1~45Msps
  • ATSC Mode :8/16-VSB,ITU-T J.83 AnnexB 64/256QAM
  • ATSC Frequency range :43MHz to 1002MHz
  • Very fast Smart Search(Blind Scan)
  • Flexible reception of SCPC & MCPC from C/Ku-Band Satellites
  • Demodulation : QPSK/8PSK/16APSK/32APSK
  • USB PVR ready (FAT16/FAT32/NTFS,Format function ,Recording,Playback,EPG Time record)
  • Two USB 2.0 Host Interface- Multimedia Application : Movie,Music, Photo and Firmware Update
  • Multimedia files playback by USB2.0(BMP/JPG/Ogg/MP3(option))
  • Satellite Scan-Simultaneous Scan,Manual PID/Satellite &TP/Network Scan
  • Supports DVB subtitle
  • 10000 Channels TV &Radio Program
  • Timer setting supports automatic Turn-ON and OFF daily
  • User-friendly EPG(Electronic Program Guide)
  • Multi language on sceen menu(OSD)
  • Up to True full Color(32bits) on screen display(OSD)
  • Powerful Channel Editing Function(Favorite,Move,Find,Sort,Delete,Skip,Lock,Edit,Create)
  • Automatic PAL/NTSC Conversion
  • 8 Favorite List
  • PIG (Picture In Graphic) ,Zoom Function
  • Screen Format : auto,4:3,16:9
  • Software Upgrade through USB ,Ethernet and RS-232C (Receiver to Receiver, PC to Receiver)
  • Hardware Copy Protection
  • Multiple LNB switching control :Diseqc 1.0/Diseqc 1.2 and USALS Compatible
  • Management Subscription
  • Network :10/100M Full /Half Duplex Ethernet Interface supported,Supports RMII interface
Satellite Tuner


  • Input Connector: F-type,IEC169-24
  • Frequency Range: 950MHz to 2150MHz
  • Input Level: -65 dBm~-25 dBm
  • LNB Power: 14V/19V (400mA Max)
  • Symbol Rate: 1 to 45Msps.(SCPC,MCPC)
  • DiSEqc: Diseqc Diseqc 1.0,1.2 & USALS Compatible
  • Demodulation: DVB-S/S2, QPSK/8PSK/16APSK/32APSK
  • Viterbi Decoding Rate: 1/2,2/3,3/4,5/6,7/8
ATSC Tuner


  • 1RF Input Connector: F-Female,IEC169-24, Loop-throught output
  • Frequency Range: 43MHz to 1002MHz
  • Sensitivity: 10dBm ~ -84dBm (ATSC 15dB SNR)
  • IF Frequency: Low IF 4~8MHz , 36,44MHz
  • Mode: 8/16-VSB,ITU-T J.83 AnnexB 64/256QAM
Transport Stream A/V Decoding


  • Demultiplex: MPEG-2 ISO/IEC 13818-1(MPEG-2 system)
  • Input stream: Max. 135Mbps in serial mode, 400Mbps in parallel mode
  • Aspect Ratio: 4:3(default), 16:9 letterbox
  • Video/Audio Decoding: MPEG 2/4, H.264 ,VC-1,AVS,VP8, Full HD Decode/ISO/IEC13818-3 Digital Audio Decoding
  • Video Resolution: 480i/p or 576i/p, 720p, 1080i,1080p
  • Video Ouput: Digital Output, CVBS,YPbPr
  • Audio Mode: Single Channel /Dual Channel, Stereo, Joint Stereo
Main CPU & Memories


  • CPU: ALI M3516 Dual 32-bit RISC CPU
  • Flash Memory: 4 Mbyte
  • External Memory Interface: DDR-3 , 256Mbyte
Data Port


  • Connector: 9 Pin D-Sub Type
  • Protocol/Data Rate: RS232 Asynchronous /Max. 115200 bps
A/V Output


  • Digital output: Digital Output, YPbPr,SPDI/F(Digital Audio Output)
  • RCA A/V: CVBS,Audio Left.Right ,Component(Y,Pb,Pr)
Rear Panel


  • Digital Output / 6RCA: Digital Output , Type A /Video, Audio L, Audio R, YPbPr
  • SPDI/F: Optical output
  • 1 Satellite /1ATSC Tuner: 1 input & 1 Loopout
  • RJ-45+USB /UHF: Ethernet+USB2.0 /Stereo Jack
  • Data Port: 9 Pin D-Sub Type (Skew Control Kit Optional)
  • Power Switch: Rocker Switch
Front Panel


  • 8 Key: PWR,CH Up/Down, Volume Up/Down,Menu,Ok,Exit
  • Display: 4 Digit 7 Segment Display
  • USB: 1 Host USB2.0
Remote Control


  • Type: IR RCU
  • Battery: 2x1.5V AAA Type
Power Supply


  • Input Voltage: AC 90-250V, 50/60Hz / Max. 20Watts
  • Type: SMPS ,AC Plug
Physical Specification


  • Operating temp.: 0 ~45
  • Dimension (WxDxH) / Weight: 260mm x 153mm x 45mm / 1.1Kg



GeoSatpro 1.2 Meter Offset Satellite Dish

Antenna Size 1.2 Meter (48 Inches)
Offset Angle 27.3 deg.
Aperture Efficiency 80%
Horizontal Axis 120 cm (47.24 in)
Vertical Axis 135 cm (53.15 in)
Assembled Weight 12.25 kg (27 lbs)
Gain @ 12.5 GHz 43dB
Focal Length 60 cm (23.62 in)
F/D Ratio .5
Mount Type U-Bolt Az / El with Fine Tuning Adjustment
Azimuth Ajustment 360 deg.
Elevation Adjustment 15 - 90 deg.
Mast Diameter Minimum: 55mm (2.16"),  Maximum 76 mm (3")
Operating Temperature -40 C - +60 C
Operational Wind Speed 90 km/H (56 mph)
Survival Wind Speed 180 km/H (112 mph)
Finish Texture Polyester Powder Coating
Material Gavanized Steel
LNB Mount Type Universal 40 mm / 23 mm clamp
Color Grey

HH120 STAB MOTOR SPECS

Communication Protocol DiSEqC1.2
Maximum Diameter Antenna 120 cm
Maximum Antenna Weight 17 kg or 37.5 lbs
Support Pole Diameter 50 83 mm or 1.96" to 3.26"
Mobile Pin Length 180 mm or 7.08"
Diameter Mobile Pin / Shaft Diamter 54 mm or 2.12"
Rotation Angle 62
Rotation Speed 0.7/s (18 V); 0.4/s (13 V)
Work Voltage 13 / 18 Vdc
Stand-by Consumption 30 mA
Work Absorption 190 mA
Max Consumption 350 mA
Operating Temperature -40C +80C
Max Relative Humidity 100%
Settable Positions (DiSEqC1.2) 49 satellites
Preset Positions (DiSEqC1.2) 28 satellites
Settable Positions (USALS) without limits
Connectors F-type
Link coaxial cable
Mechanical Limits 70
Settable Electronic Limits 5 65
Fine Rotation 0.1 impulses
Rotor Tilting 15 70
Weight 3200 g or 7 lbs

Deluxe Motorized 1.2 Meter Ku-Band Satellite System - Global Star System 400

This System Includes the 9000i Linkbox Satellite Receiver that can do DVB-S, DVB-S2, QPSK, 8PSK, 16APSK, MPEG2, MPEG4, Standard and High Definition.
GEO SAT PRO 1.2 Meter Satellite Dish, to gather a stronger Signal and have Less Rain Fade.
HH120 STAB Motor, Our Best Ku LNBF, KSC322 Dual Outlet LNBF and an Installation Kit that includes 1 - 25' and 1 - 75' Black RG6 Coax Cables.

Item # GLOBAL STAR SYS 400 - $659.00 Includes Shipping
Within the 48 Cont. United States

Signal Meter SF95 for $14.95 - This can be helpful in aiming in the dish to locate the satellited.


GLOBAL STAR MOTORIZED 400 SATELLITE SYSTEM
